N700E INSTRUCTION MANUAL
1-17
1.5.5 N700E-550LF/750LFP, N700E-750LF/900LFP
10.24 inch
10.83 inch [D]
2-Φ12 0.47 inch
0.59 inch
13.58 inch [W]
9.06 inch [W1]
29.92 ihch [H]
28.94 ihch [H1] 0.63 inch0.35 inch
2- 0.47 inch
9.06 inch [W1]
Figure 1-12: Physical Dimension Specific to 550LF ~ 750LF
