3.1.6 Expanded Function Mode of H Group
Code
Name
Edit
Range
Unit
Res
Default
Motor Parameters
H01
Auto Tuning
X
0: OFF
1: ON
-
-
0
H02
Motor Data Select
X
0: Standard Data
1: Auto Tune Data
-
-
0
H03
Motor Capacity
X
3L(3 HP)
5L(5 HP)
7.5L(7.5 HP)
10L(10 HP)
15L(15 HP)
20L(20 HP)
25L(25 HP)
30L(30 HP)
40L(40 HP)
50L(50 HP)
60L(60 HP)
75L(75 HP)
100L(100 HP)
125L(125 HP)
3H(3 HP)
5H(5 HP)
7.5H(7.5 HP)
10H(10 HP)
15H(15 HP)
20H (20 HP)
25H (25 HP)
30H (30 HP)
40H (40 HP)
50H (50 HP)
60H (60 HP)
75H (75 HP)
100H (100 HP)
125H (125 HP)
150H (150 HP)
200H (200 HP)
250H (250 HP)
275H (275 HP)*
300H (300 HP)
350H (350 HP)*
400H (400 HP)
425H (425 HP)*
450H (450 HP)
500H (500 HP)
-
-
-
H04
Motor Poles Setting
X
2
4
6
8
4
H05
Motor Rated Current
X
0.1 to 800.0
A
0.1
-
H06
Motor Flux Current
X
0.1 to 400.0
A
0.1
-
H07
Motor Rated Slip
X
0.01 to 10.0
%
0.1
-
H08
Motor Resistance R1
X
0.1 to 3000.0
mΩ
0.1
-
H09
Transient Inductance
X
0.001 to 30.000
mH
0.001
-
H10
Motor Resistance R1 Auto
Tuning Data
X
0.1 to 3000.0
mΩ
0.1
-
H11
Transient Inductance
Auto Tuning Data
X
0.001 to 30.000
mH
0.001
-
* When b26 is set to 1, this motor series is displayed.(275H,350H,425H)
