1.6 Transportation
Please inspect following
Handle according to the weight of the product.
Do not stack the inverter boxes higher than the number recommended on boxes
Install according to instructions specified in this manual
Do not open the cover during delivery
Do not place heavy items on the inverter
1.7 Unpacking
Please inspect following
No damage made to the unit during transportation
One Operational Manual is enclosed
Check the Label Specification if the correct product is delivered per your order
Model : N700E-110LF/150LFP Max Temp : 40deg
OUTPUT CAPACITY : 17.1kVA / 19kVA IP20
INPUT : 3Ph, 200-240V, 50/60Hz, 47.4A
OUTPUT : 3Ph, 0-240V, 0.01-400Hz, 45A(HD)
BAR CODE
Figure 1-19: Outlook of N700E Figure 1-20: N700E Specification on Label
