N700E INSTRUCTION MANUAL
1-5
1.3.3 N700E Performance Specification
Features
Performance Specification
Control Method
(Note3)
V/f control, Sensorless Vector control
Output Frequency
Range
(Note4)
0.01∼400Hz (Sensorless Vector Control : 0.5 ∼ 300Hz)
Frequency Accuracy
Digital command ±0.01% of Max Frequency / Analog Frequency ±0.1% (25±10℃)
Frequency Resolution
Digital Setting : 0.01Hz (Under 100Hz), 0.1Hz (Over 100Hz)
Analog setting: Max. frequency / 1,000 (DC 0∼10V, 4∼20mA)
Voltage/frequency
Characteristic
Constant Torque, Variable Torque
Overload Current Rate
Heavy Duty(150%, 60sec), Normal Duty(120%, 60sec)
Acceleration/Deceleration
0.1∼3000 sec (Linear, S curve, U curve)
DC Injection Braking
Separately configurable start and stop up to 10 sec, 100 % motor rated current
Input Signal
Frequency
 Set by Keypad (Potentiometer or Arrow Keys)
 Input voltage: DC 0∼10V (Input impedance 10KΩ)
 Input current: DC 4∼20mA (Input impedance 200Ω)
Run/Stop
 Run / Stop key
 Input Terminal: Forward Run/Reverse Run
 Input Terminal: Start, Stop, FW/RV Selection
Intelligent Input
Terminal
 FW(Forward Run), RV(Reverse Run),
 CF1~4(Multi-speed Inputs 1~4),
 RS(Reset),
 AT(Analog input current/voltage selection signal),
 USP(Unattended Start Protection)
 EXT1~6(External trip 1~6),
 FRS(Free-Run Stop),
 JG(Jogging),
 SFT(software lock),
 2CH(2nd Acceleration / Deceleration),
 STA, STP, F/R(3-wire)
 UP, DOWN(Up/down), UP/DOWN initial value clear
 O/R (Local Keypad Operation), T/R(Local Terminal Input Operation),
 PIDIR(PID Integral Reset),
 PIDD(PID Disabled)
 F/O (Frequency Override), R/O (Reset Override)
Feature
Performance Specification
Output Signal
Intelligent Output
Terminal
(RN0-RN1,RN2-RN3,
AL0-AL1-AL2)
 RUN(Run Status Signal),
 FA1 (Frequency Arrival Signal 1),
 FA2 (Frequency Arrival Signal 2),
 OL(Overload Alarm),
 OD(PID Error Deviation Signal),
 FLT(Fault Signal)
 COM(Operation by Communication)
 SOL(System Overload)/SUL(System Underload)
FM Output
Analog Output Meter (DC 0~10V full scale. Max ∙ 1mA)
Output Frequency, Output Current, Output Voltage, Output Power, Output Torque,
Operation by Communication
AMI Output
Analog Output Meter (4~20mA full scale. Max ∙ 250Ω)
Output Frequency, Output Current, Output Voltage, Output Power, Output Torque,
Operation by Communication

Hyundai N700E Specifications

General

Brand	Hyundai
Model	N700E
Category	Inverter
Language	English
