CAUTION FOR UL/cUL REQUIREMENTS
THE HYUNDAI ELECTRIC N700E VFD UL FILE NUMBER IS E205705
(Except N700E-300LF/370LFP ~ N700E-750LF/900LFP) AND FILE NUMBER IS E479086
(N700E-300LF/370LFP ~ N700E-750LF/900LFP)
CONFIRMATION OF UL LISTING CAN BE FOUND ON THE UL WEB SITE: www.ul.com
DO NOT CONNECT OR DISCONNECT WIRING, OR PERFORM SIGNAL CHECKS WHILE THE
POWER SUPPLY IS TURNED ON.
THERE ARE LIVE PARTS INSIDE THE VFD. NEVER TOUCH THE PRINTED CIRCUIT BOARD
(PCB) WHILE THE POWER SUPPLY IS TURNED ON.
[WARNING] THE BUS CAPACITOR DISCHARGE TIME IS 5 MINUTES. BEFORE STARTING
WIRING OR INSPECTION, SWITCH POWER OFF, WAIT FOR MORE THAN 5 MINUTS, AND
CHECK FOR RESIDUAL VOLTAGE BETWEEN TERMINAL P (+) AND N (-) WITH A METER ETC.,
TO AVOID HAZARD OF ELECTRICAL SHOCK.
[SHORT CIRCUIT RATING] THIS VFD IS SUITABLE FOR USE ON A CIRCUIT CAPABLE OF
DELIVERING NOT MORE THAN ___*1___ARMS SYMMETRICAL AMPERES, 480 VOLTS FOR HF
TYPE AND 240 VOLTS FOR LF TYPE MAXIMUM.
BRANCH CIRCUIT SHORT CIRCUIT PROTECTION SHALL BE PROVIDED BY FUSE ONLY.
*1 N700E MODELs and KA VALUE
N700E-055LF/075LFP ~ N700E-300LF/370LFP
N700E-055HF/075HFP ~ N700E-370HF/450HFP
N700E-370LF/450LFP ~ N700E-750LF/900LFP
N700E-450HF/550HFP ~ N700E-1320HF/1600HFP
N700E-1600HF/2000HFP ~ N700E-2200HF/2500HFP
N700E-2800HF/3200HFP ~ N700E-3500HF/3800HFP
[OVERSPEED PROTECTION] THIS VFD DOES NOT PROVIDE OVERSPEED PROTECTION
[MOTOR OVERLOAD PROTECTION] THIS VFD PROVIDES MOTOR OVERLOAD PROTECTION.
OVERLOAD PROTECTION LEVEL IS 20 ~ 120% OF FULL LOAD CURRENT. THE PROTECTION
LEVEL MAY BE ADJUSTED BY PARAMETER (b04). REFER TO THE N700E USER GUIDE OR
CATALOG.
[MOTOR OVERTEMPERATURE] MOTOR OVERTEMPATURE SENSING IS NOT PROVIDED BY
THE VFD.
[ENVIRONMENT]
MAXIMUM AMBIENT TEMPERATURE
40℃(WHEN CARRIER FREQUENCY EQUAL TO OR
LESS THAN DEFAULT VALUE)
90% RH OR LESS(NO CONDENSING)
INDOORS(NO CORROSIVE AND FLAMMABLE GASES,
OIL MIST, DUST AND DIRT)
