One: System Overview 9
Providing a brighter solution.™
Additional Detail on Key Components
Hand-Held Controller (PE953)
The main function of the Hand-Held Controller is to transmit user
commands to the PE653 Receiving Device, PE650 Receiving Device, and/
or Z-Wave home control devices, and to display the status of the installed
equipment.
The unit floats if thrown in the pool or spa, is water-submersible, shock
resistant, and requires three (3) AA batteries. Expected battery life is about
one year in typical use.
When the components of a specific system are linked together into
a network, unique network ID codes supplied by the PE953 prevent
unauthorized use of the system by neighboring systems.
24-Volt Valve Actuator (PE24VA)
Designed with quality in mind, Intermatic’s 24-volt valve actuators
provide reliable control of 2-way and 3-way diverter valves for pool/
spa combinations and water features. The water flow can be altered
for specific applications through the adjustable cam, which rotates
diverter valves to multiple degree settings. The cam settings can be
easily adjusted by simply removing the lid. These valve actuators are
compatible with all pool/spa valves currently offered in the industry and
will retrofit into all pool/spa control systems.
24VAC Input Voltage•
Automates compatible diverter valves for •
pool/spa combos
Adjustable cam rotates diverter valves to •
multiple degree settings
Designed to operate most 2-way and 3-way diverter valves •
Shipping Weight - 3 lbs. (1.4 kg) •
Agency Approval - CSA/C-US•
Water Temperature Sensor (PA122)
The Intermatic Water Sensor (PA122) monitors both pool and spa water
temperature, depending on the position of the diverter valves. Installation is
necessary for the thermostatic control to work. The sensor can be ordered
separately.
