SV-DA200 series AC servo drive Function codes
-132-
This parameter is used to set the torque feedforward selection.
Set value
Role
[0]
Speed command feedforward
1
Position command feedforward
P2.85
Data size
16bit
Data format
DEC
Modbus address
1570, 1571
CANopen address
0x2255, 0x00
P2.86
Field weakening control
switch
Setting range
Default
Unit
Available mode
0–3
0
-
P
S
T
This parameter is used to control the field weakening and its mode.
Set value
Role
[0]
Invalid
1
Open-loop field weakening
2
Closed-loop field weakening
3
Closed-loop field weakening with feedforward
P2.86
Data size
16bit
Data format
DEC
Modbus address
1572, 1573
CANopen address
0x2256, 0x00
P2.87
Voltage utilization rate of
field weakening control
Setting range
Default
Unit
Available mode
1–99
90
%
P
S
T
This parameter is used to set the voltage utilization rate of field weakening control.
P2.87
Data size
16bit
Data format
DEC
Modbus address
1574, 1575
CANopen address
0x2257, 0x00
P2.88
Bandwidth of open-loop
field weakening
Setting range
Default
Unit
Available mode
1–500
50
%
P
S
T
This parameter is used to set the width of open-loop field weakening.
P2.88
Data size
16bit
Data format
DEC
Modbus address
1576, 1577
CANopen address
0x2258, 0x00
P2.89
Bandwidth of closed-loop
field weakening
Setting range
Default
Unit
Available mode
1–100
20
%
P
S
T
This parameter is used to set the width of closed-loop field weakening.
P2.89
Data size
16bit
Data format
DEC
Modbus address
1578, 1579
CANopen address
0x2259, 0x00
P2.90
Max. field weakening
current limit of closed-loop
field weakening
Setting range
Default
Unit
Available mode
1–100
90
%
P
S
T
This parameter is used to set the max. field weakening current limit of closed-loop field
weakening.
