SV-DA200 series AC servo drive Control mode applications
-58-
Vibration control switching input
The function is the control signal of 1
st
and 2
nd
vibration control frequency.
When the digital input is valid, the internal software uses P1.38; when invalid, use P1.36.
This function is the control signal of the fast stop of external control.
When the digital input is valid, the motor decelerates to 0 from current speed at the curve set by
P0.69; when the input is invalid, the motor will restore to the operation state before stop.
This function is the control signal of stopping PTP operation in the PTP control mode. In the bus
control mode, it has the same function with P5.20 when it is 2048.
Absolute position clearing
This function is used to clear the multi-turn absolute encoder.
When this digital input is valid, the multi-turn data of the encoder will be cleared while the
single-turn data remains unchanged, however, the absolute position feedback of the system will
be cleared.
This function is forward jogging. When this digital input is valid, forward jogging operation will be
applied.
This function is reverse jogging. When this value is valid, reverse jogging operation will be
applied.
High/low speed switching of jogging
This function is high/low speed switching of jogging. When this digital input is valid, high speed
jogging will be applied.
JOG function of the terminal
When this digital input is valid, JOG function of the terminal is valid.
