INVT SV-DA200-4R4-4 User Manual

SV-DA200 series AC servo drive Function codes
-219-
R1.02
Original voltage of analog input 1
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the original voltage value of analog input channel 1
R1.02
Data size
32bit
Data format
DEC
Modbus address
4204, 4205
CANopen address
0x3102, 0x00
R1.03
Original voltage of analog input 2
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the original voltage value of analog input channel 2
R1.03
Data size
32bit
Data format
DEC
Modbus address
4206, 4207
CANopen address
0x3103, 0x00
R1.04
Original voltage of analog input
3
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the original voltage value of analog input channel 3
R1.04
Data size
32bit
Data format
DEC
Modbus address
4208, 4209
CANopen address
0x3104, 0x00
R1.05
Voltage of analog input 1
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the calibrated voltage value of analog input channel 1.
R1.05
Data size
32bit
Data format
DEC
Modbus address
4210, 4211
CANopen address
0x3105, 0x00
R1.06
Voltage of analog input 2
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the calibrated voltage value of analog input channel 2
R1.06
Data size
32bit
Data format
DEC
Modbus address
4212, 4213
CANopen address
0x3106, 0x00
R1.07
Voltage of analog input 3
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the calibrated voltage value of analog input channel 3
R1.07
Data size
32bit
Data format
DEC
Modbus address
4214, 4215
CANopen address
0x3107, 0x00
R1.08
Voltage of analog output 1
Display range
Precision
Unit
-10.000–10.000
0.001
V
Display the output voltage value after offset treatment of analog output channel 1
R1.08
Data size
32bit
Data format
DEC
Modbus address
4216, 4217
CANopen address
0x3108, 0x00
