KE-2050/KE-2060, KE-2050R/2055R/KE-2060R Maintenance Manual
14-31
Two DIP switches (i.e. the MODE switch and the OPTION switch) are provided for each axis
respectively on the board in the cover. It is not needed to change the default settings. When you
check the settings, see the figure below.
MODE switch
OPTION switch
Figure 14-5-3-2 DIP Switch Setting of the Magnescale
