Jungheinrich EKS 314 User Manual

D 7
0108.USA
3.2 Dimensions (as per data plate)
1)
ZT mast performance data measured for 600 DZ.
Description EKS 314
h
1
Mast height (retracted)
1)
109.5 inch 2780 mm
h
3
Lift
1)
236.2 inch 6000 mm
h
4
Mast height (extended)
1)
327.6 inch 8320 mm
h
6
Height above overhead guard 91.3 inch 2320 mm
h
7
Height 8.3 inch 210 mm
h
12
Truck height raised
1)
244.5 inch 6210 mm
h
15
Stockpicking height
1)
307.5 inch 7810 mm
Ast Working aisle width for pallets 39.4 x
47.2 inch (1000 x 1200 mm) trans.
55.1 inch 1400 mm
b
1
Chassis width 39.4 inch 1000 mm
b
5
Distance between forks, outer 22.7 -31.3 inch 576 -794 mm
b
6
Width across guide rollers 51.2 inch 1300 mm
b
10
Width across front axle 42 inch 1067 mm
l
1
Overall length w.o. load 118.5 inch 3010 mm
l
2
Length incl. fork shank 76.4 inch 1940 mm
l Fork length 42 inch 1067 mm
W
a
Turning radius 66.1 inch 1680 mm
m
1
Ground clearance below forks 0.98 inch 25 mm
m
2
Ground clearance from center of
wheelbase
2.56 inch 65 mm
x Load distance 7.5 inch 190 mm
y Wheelbase 59.8 inch 1520 mm
Net weight incl. battery, w.o. load 7672.1 lb 3480 Kg
D 7
0108.USA
3.2 Dimensions (as per data plate)
1)
ZT mast performance data measured for 600 DZ.
Description EKS 314
h
1
Mast height (retracted)
1)
109.5 inch 2780 mm
h
3
Lift
1)
236.2 inch 6000 mm
h
4
Mast height (extended)
1)
327.6 inch 8320 mm
h
6
Height above overhead guard 91.3 inch 2320 mm
h
7
Height 8.3 inch 210 mm
h
12
Truck height raised
1)
244.5 inch 6210 mm
h
15
Stockpicking height
1)
307.5 inch 7810 mm
Ast Working aisle width for pallets 39.4 x
47.2 inch (1000 x 1200 mm) trans.
55.1 inch 1400 mm
b
1
Chassis width 39.4 inch 1000 mm
b
5
Distance between forks, outer 22.7 -31.3 inch 576 -794 mm
b
6
Width across guide rollers 51.2 inch 1300 mm
b
10
Width across front axle 42 inch 1067 mm
l
1
Overall length w.o. load 118.5 inch 3010 mm
l
2
Length incl. fork shank 76.4 inch 1940 mm
l Fork length 42 inch 1067 mm
W
a
Turning radius 66.1 inch 1680 mm
m
1
Ground clearance below forks 0.98 inch 25 mm
m
2
Ground clearance from center of
wheelbase
2.56 inch 65 mm
x Load distance 7.5 inch 190 mm
y Wheelbase 59.8 inch 1520 mm
Net weight incl. battery, w.o. load 7672.1 lb 3480 Kg
