4.1 Truck data plate
NOTICE For queries relating to the truck or spare parts orders, please state the truck
serial number (21).
4.2 Capacity
The capacity plate (11) gives the capacity (Q in lbs / kg) of the truck as a function of
the load center of gravity distance (D in inch / mm) and lift height (h
3
in inch / mm) in
tabular form.
Item Description Item Description
20 Option 29 Manufacturer's logo
21 Serial number 30 Max. lift height
22 Load center distance 31 Residual lift capacity
23 Year of manufacture 32 Battery weight min.
24 Battery ID 33 Max. Battery capacity
25 Hour Rate 34 System voltage
26 Battery weight max. 35
Weight of truck without battery
+/- 5%
27 Nominal power 36 Rated capacity
28 Manufacturer 37 Model
for type "E" industrial trucks with type "E" battery
Built in compliance with ASME B 56.1
20
21
22
23
24
25
26
27
28
29
37
36
35
34
33
32
31
30
D (mm)
h3 (mm) Q (kg)
D (inch)
h3 (inch) Q (lbs)
