1005.USA
E 6
1.3 Truck operational status symbols
The operational status of the truck when it is switched on is indicated by symbols in
the display unit.
Safety gates open
Foot switch not pressed
When the following symbols are displayed you must carry out a reference movement
in accordance with the display, i.e. the Main Lift must be raised approx. 10 cm/3.94
inch and then lowered again. This is the only way for the controller to release all the
truck movements at full speed.
Referencing: lift - raise
Referencing: lift - lower
Lift cutout for referencing
QwW When disabling the lift cutout the driver must look
out for obstacles when the mast is extended.
Pressing the “lift cutout override” switch disables the lift
cutout.
1005.USA
E 6
1.3 Truck operational status symbols
The operational status of the truck when it is switched on is indicated by symbols in
the display unit.
Safety gates open
Foot switch not pressed
When the following symbols are displayed you must carry out a reference movement
in accordance with the display, i.e. the Main Lift must be raised approx. 10 cm/3.94
inch and then lowered again. This is the only way for the controller to release all the
truck movements at full speed.
Referencing: lift - raise
Referencing: lift - lower
Lift cutout for referencing
QwW When disabling the lift cutout the driver must look
out for obstacles when the mast is extended.
Pressing the “lift cutout override” switch disables the lift
cutout.
