8-Port Gigabit Ethernet SFP XPIM Components
The 8-Port Gigabit Ethernet small form-factor pluggable Gigabit-Backplane Physical
Interface Module (SFP XPIM) contains the components listed in Table 49 on page 92.
Table 49: 8-Port Gigabit Ethernet SFP XPIM Components
DescriptionLocationComponent
Use the ONLINE/OFFLINE button to
gracefully shut down the XPIM. Press down
and hold the button for 4 to 5 seconds;
then release. The XPIM gracefully shuts
down and turns off the power supply units
(PSUs).
To power up the XPIM (if the Services and
Routing Engine [SRE] is off), press and
hold the ONLINE/OFFLINE button for 4 to
5 seconds.
Right side of the XPIMONLINE/OFFLINE button
Dual female 75-ohm BNC coaxial
connectors: TX (transmit) and RX
(receive).
Middle/right of the
XPIM
TX and RX coaxial
connectors
Use the captive screws to hold the XPIM
in place.
One on each side of
the XPIM
Two captive screws
