Juniper SRX650 User Manual

Table 70: RJ-48 Connector to RJ-48 Connector (Straight)
Pinouts (continued)
Signal
RJ-48 Pin (Data
Numbering Form)
RJ-48 Pin (on 1-Port
T1/E1 Mini-PIM)
No connectNo connect7
No connectNo connect8
Related
Documentation
RJ-48 Connector to RJ-48 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 128
•
• RJ-48 Connector to DB-15 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 129
• RJ-48 Connector to DB-15 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 130
• 1-Port T1/E1 Mini-Physical Interface Module Overview on page 65
RJ-48 Connector to RJ-48 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module
Table 71 on page 128 gives RJ-48 connector to RJ-48 connector (crossover) pinouts for
the 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM).
Table 71: RJ-48 Connector to RJ-48 Connector (Crossover) Pinouts
Signal
RJ-48 Pin (Data
Numbering Form)
RJ-48 Pin (on
T1/E1 Mini-PIM)
RX/Ring/– <––>TX/Ring/–41
RX/Tip/+ <––>TX/Tip/+52
TX/Ring/– <––>RX/Ring/–14
TX/Tip/+ <––>RX/Tip/+25
Shield/Return/Ground33
Shield/Return/Ground66
No connectNo connect7
No connectNo connect8
Related
Documentation
RJ-48 Connector to RJ-48 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 127
•
Copyright © 2015, Juniper Networks, Inc.128
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
