• RJ-48 Connector to RJ-48 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 128
• RJ-48 Connector to DB-15 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 130
• 1-Port T1/E1 Mini-Physical Interface Module Overview on page 65
RJ-48 Connector to DB-15 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module
Table 73 on page 130 gives RJ-48 connector to DB-15 connector (crossover) pinouts.
Table 73: RJ-48 Connector to DB-15 Connector (Crossover) Pinouts
Signal
DB-15 Pin (Data Numbering
Form)
RJ-48 Pin (on
T1/E1 Mini-PIM)
RX/Ring/– <––>TX/Ring/–91
RX/Tip/+ <––>TX/Tip/+12
TX/Ring/– <––>RX/Ring/–114
TX/Tip/+ <––>RX/Tip/+35
Shield/Return/Ground43
Shield/Return/Ground26
No connectNo connect7
No connectNo connect8
No connectNo connect9
No connectNo connect10
No connectNo connect11
No connectNo connect12
No connectNo connect13
No connectNo connect14
No connectNo connect15
Related
Documentation
• RJ-48 Connector to RJ-48 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 127
Copyright © 2015, Juniper Networks, Inc.130
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
