RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module
Table 86 on page 152 gives the RS-422/449 DTE cable pinouts.
Table 86: RS-422/449 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Shield Ground-115
Send Data (A)59460
Send Timing (A)55556
Receive Data (A)261
Request to Send (A)47748
Receive Timing (A)685
Clear to Send (A)38937
Local Loopback-1041
Data Mode (A)10119
Terminal Ready (A)341233
Receive Ready (A)141313
Terminal Timing (A)511752
Signal Ground-1936
Receive Common-204
Send Data (B)602259
Send Timing (B)562355
Receive Data (B)1242
Copyright © 2015, Juniper Networks, Inc.152
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
