• Quad CT1/E1 GPIM Basic Configuration on page 238
Quad CT1/E1 GPIM Key Features
The Quad CT1/E1 Gigabit-Backplane Physical Interface Module (GPIM) provides the
following common key features for both T1 and E1 modes:
•
Channel service unit/data service unit (CSU/DSU) to eliminate the need for a separate
external device
•
56-Kbps and 64-Kbps operating modes
•
Independent internal and external clocking option
•
Alarm reporting with a 24-hour history maintained
•
Loopback (local and remote) and BERT/PRBS diagnostics
•
Multilink Frame Relay and Multilink PPP support
•
MTU size of 9000 bytes (maximum)
Related
Documentation
Quad CT1/E1 GPIM Overview on page 121•
• Quad CT1/E1 GPIM Network Interface Specifications on page 28
• Quad CT1/E1 GPIM Hardware Specifications on page 123
• Quad CT1/E1 GPIM LEDs on page 124
• Quad CT1/E1 GPIM Components on page 122
• Quad CT1/E1 GPIM Basic Configuration on page 238
Quad CT1/E1 GPIM Hardware Specifications
The Quad CT1/E1 Gigabit-Backplane Physical Interface Module (GPIM) has the
specifications listed in Table 68 on page 123.
Table 68: Quad CT1/E1 GPIM Hardware Specifications
ValueDescription
0.78 in. H x 6.72 in. W x 8.1 in. L
(19.8 mm x 170.8 mm x 205.7 mm)
Dimensions (H x W x L)
15.4 oz (0.44 kg)Weight
RJ-45Connector type
Single-high, single-wide GPIMForm factor
32°F through 104°F (0°C through 40°C)Environmental operating temperature
123Copyright © 2015, Juniper Networks, Inc.
Chapter 18: Quad CT1/E1 GPIM
