Table 30: 1-Port ADSL2+ Mini-PIM LED States
DescriptionStateColorLED
Indicates that the ADSL interface is trainedOnGreenSYNC
Indicates training is in progressBlinking
Indicates that the interface is idleOff
Indicates that traffic is passing throughBlinkingGreenTX/RX
Indicates that no traffic is passing throughOff
Related
Documentation
1-Port ADSL2+ Mini-Physical Interface Module Overview on page 45•
• 1-Port ADSL2+ Mini-Physical Interface Module Hardware Specifications on page 47
• 1-Port ADSL2+ Mini-Physical Interface Module Network Interface Specifications on
page 21
• 1-Port ADSL2+ Mini-Physical Interface Module Supported Standards on page 48
• 1-Port ADSL2+ Mini-Physical Interface Module Key Features on page 46
• 1-Port ADSL2+ Mini-Physical Interface Module Supported Loopback Diagnostics on
page 49
• 1-Port ADSL2+ Mini-Physical Interface Module Basic Configuration on page 209
1-Port ADSL2+ Mini-Physical Interface Module Supported Standards
The 1-Port ADSL2+ Mini-Physical Interface Module (Mini-PIM) supports the following
standards:
•
ANSI T1.413 Issue 2 (Annex A only)
•
ITU G.992.1 (G.dmt)
•
ITU G.992.3 (ADSL2)
•
ITU G.992.5 (ADSL2+)
Related
Documentation
1-Port ADSL2+ Mini-Physical Interface Module Overview on page 45•
• 1-Port ADSL2+ Mini-Physical Interface Module Hardware Specifications on page 47
• 1-Port ADSL2+ Mini-Physical Interface Module Network Interface Specifications on
page 21
• 1-Port ADSL2+ Mini-Physical Interface Module Key Features on page 46
• 1-Port ADSL2+ Mini-Physical Interface Module LEDs on page 47
• 1-Port ADSL2+ Mini-Physical Interface Module Supported Loopback Diagnostics on
page 49
Copyright © 2015, Juniper Networks, Inc.48
