CHAPTER 27
Mini-Physical Interface Module and
Gigabit-Backplane Physical Interface
Module Operating Modes and Supported
Modules
•
1-Port G.SHDSL 8-Wire Mini-Physical Interface Module Operating Modes on page 241
1-Port G.SHDSL 8-Wire Mini-Physical Interface Module Operating Modes
The 1-Port G.SHDSL 8-Wire Mini-Physical Interface Module (Mini-PIM) can be configured
to operate in the following modes:
•
4X2-wire (4-port 2-wire)
•
2X4-wire (2-port 4-wire)
•
1X8-wire (1-port 8-wire)
NOTE: The 4-wire mode is the default operating mode for the 1-Port
G.SHDSL 8-Wire Mini-PIM.
The 1-Port G.SHDSL 8-Wire Mini-PIM can operate in any of the following annexes:
•
Annex A
•
Annex B
•
Annex F
•
Annex G
NOTE: All the annexes supported on the 1-Port G.SHDSL 8-Wire Mini-PIM
can operate in 2-wire, 4-wire, and 8-wire modes.
Table 104 on page 242 lists the 1-Port G.SHDSL 8-Wire Mini-PIM data rates for the different
operating modes.
241Copyright © 2015, Juniper Networks, Inc.
