JVC GY-HM150U User Manual

98
Others
Camera Recorder
Accessories
AC Adapter
Specifications
 General
Power : DC 11 V (using AC adapter)
DC 7.2 V (using battery)
Power
consumption
: Approx. 8.3 W
(when backlight is set to [STANDARD] while
the LCD monitor or viewfinder is in use)
Dimensions : 366 mm (W) × 179 mm (H) × 138 mm (D)
(14-4/8" x 7-1/8" x 5-4/8")
Mass : Approx. 1190 g (2.7 Ibs)
Approx. 1320 g (2.9 Ibs) (incl. battery
BN-VF823U, SD card, micorophone)
Allowable
operating
temperature
: 0 f to 40 f (32 J to 104 J)
Allowable
operating
humidity
: 35 % RH to 80 % RH
Allowable
storage
temperature
: -20 f to 50 f (-4 J to 122 J)
Image pickup
device
: 1/4", Progressive CCD3
Lens : F1.8 to 2.8
f = 3.7 mm to 37 mm
Filter diameter : When the hood is detached
46 mm (screw pitch: 0.75 mm)
Compatible with filter (external diameter:
50 mm and below),
tele-converter, and wide-converter
When the hood is attached
72 mm (screw pitch: 0.75 mm)
Compatible with filter (external diameter:
75 mm and below) only
* When removing the filter, do not press on
the top and bottom of the hood. Doing so
makes it difficult to remove the filter and
may damage the inner surface of the
hood.
Zoom : Up to 10x (optical zoom)
LCD screen : 2.7", 16:9, 230,000 pixels
Viewfinder : 0.24", 16:9, 260,000 pixels
 Video/Audio
Recording time : Approx. 25 minutes (8 GB SDHC/
SDXC card, 35 Mbps, VBR mode)
Video recording file
format
: QuickTime File Format
(For Final Cut Pro)
MP4 File Format (HD only)
AVI File Format (SD only)
: Video signal
HD (HQ mode) : MPEG-2 Long GOP
VBR, 35 Mbps (Max) MPEG-2
HD (SP mode) : MPEG-2 Long GOP
CBR, 25 Mbps (1440x1080i) /19 Mbps
(1280x720p) MPEG-2
SD : DV
CBR, 25 Mbps
(720x480i: GY-HM150U only) /
(720x576i: GY-HM150E only)
: Audio signal : LPCM 2ch, 48 kHz/16 Bit
Video format
: NTSC setting
HD (HQ mode) : 1920x1080/59.94i, 29.97p, 23.98p,
1440x1080/59.94i, 1280x720/59.94p,
29.97p, 23.98p
HD (SP mode) : 1440x1080/59.94i, 1280x720/59.94p,
29.97p, 23.98p
SD : 720x480/59.94i (GY-HM150U only)
: PAL setting
HD (HQ mode) : 1920x1080/50i, 25p, 1440x1080/50i,
1280x720/50p, 25p
HD (SP mode) : 1440x1080/50i, 1280x720/50p, 25p
SD 720x576/50i (GY-HM150E only)
 Ter m i na ls
AV terminal : Video Analog output 1.0 V (p-p), 75 K
Audio Analog output (stereo)
-8 dBu, 1 k
K (when reference level -12 dB
is selected)
-16 dBu, 1 k
K (when reference level -20 dB
is selected)
Component terminal : Y, P B, PR component output
Y: 1.0 V (p-p), 75 K
P
B, PR: 700 mV (p-p), 75 K
HDMI terminal : HDMI Connector
USB terminal : Mini USB-B type, USB 2.0
Headphone jack : 3.5 mm mini jack (stereo)
Remote terminal : 3.5 mm mini jack (4-pin)
Audio INPUT1/INPUT2 terminals
MIC : -60 dBu, 3 kK, XLR (balanced),
+48 V output (phantom power supply)
LINE : +4 dBu, 10 kK, XLR (balanced)
AC adapter ...................................................................................1
Power cord (GY-HM150U) ............................................................2
Power cord (GY-HM150E) ............................................................4
Battery..........................................................................................1
Battery charger.............................................................................1
Remote control unit ......................................................................1
Audio unit......................................................................................1
Microphone...................................................................................1
AV cord.........................................................................................1
Component cable .........................................................................1
CD-ROM.......................................................................................1
Instruction manual ........................................................................1
Warranty card (GY-HM150U only)................................................1
Power : AC 100 V to 240 V, 50 Hz/60 Hz
Output : DC 11 Vd, 1 A
Allowable
operating
temperature
: 0 f to 40 f (32 J to 104 J)
Dimensions : 49 mm (W) × 26 mm (H) × 64 mm (D)
(1-15/16" x 1-1/8" x 2-7/8")
(excluding cord and AC plug)
Mass : Approx. 86 g (0.19 Ibs)
GY-HM150U.book Page 98 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
