JVC GY-HM150U User Manual

93
Folders in the SDHC/SDXC Card
Images captured are recorded to [PRIVATE]B[JVC] folder
inside the SDHC/SDXC card.
Images recorded are sorted into the respective folders
according to the menu settings below.
Memo :
● By formatting (initializing) the SDHC/SDXC card from the
[Format Media] menu on the camera recorder, folders
required for recording in the current [System Definition]
settings and [File Format] settings will be generated.
● When the [System Definition] settings and [File Format]
settings are changed, folders required for recording in those
settings will be automatically generated.
Note :
● When a clip inside the folder is moved or deleted using the
Explorer (Windows) or Finder (Mac), recording to the
SDHC/SDXC card may fail if formatting (initializing) of the
card is not performed.
Clip (Recorded Data) and Clip Name
When recording is stopped, the images, audio and
accompanying data which are recorded from start to stop are
recorded as one “clip” on the SDHC/SDXC card.
An 8-character clip name is automatically generated for the
recorded clip. (Clip Name Prefix + Clip Number)
Example:
Clip Name Prefix (any 4 alphanumeric characters)
This is set to AxxxGB (AxxxB denotes the last 3 digits of the
serial number) by default.
Memo :
● Before recording starts, you can set any characters for the
clip name prefix by using [Main Menu]B[Record
Set]B[Clip Set]B[Clip Name Prefix]. (A Page 64)
● Changes cannot be made after recording.
Recorded Clips
Recorded materials may be split into several files by this
camera recorder due to the file size. However, they can be
played back continuously on the camera recorder. Clips may
be recorded across the two SDHC/SDXC cards in card slots
A and B depending on the recording time of the clip.
When copying clips to a HDD using a PC, it is recommended
to use [JVC Clip Manager Software], which is found in the
bundled CD-ROM, to maintain continuity.
Note :
● A clip recorded across several cards cannot be played
back continuously. Continuous playback is only possible
when the recording is made on one card.
Clips Recorded to SDHC/
SDXC Cards
System Definition
Setting
File Format Setting Record Folder
HD (MPEG2) MOV CQAV
HD (MPEG2) MP4 BPAV
SD (DV) MOV CQDV
SD (DV) AVI CADV
ABCG0001
Clip Number
A number in automatic ascending order is
assigned in the recording order.
The clip number can be reset in the menu.
* [Main Menu]B[Record Set]B[Clip
Set]B[Reset Clip Number] (A Page 64)
GY-HM150U.book Page 93 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
