JVC GY-HM150U User Manual

73
* Default values are indicated in bold characters.
A/V Out Menu
Item Setting Values Function
Display On TV
On
Off
For specifying whether to enable on-screen display on the external monitor.
On : Turns on display.
Off : Turns off display.
Video Output
4:3
16:9
For selecting the monitor type of the external monitor to be connected to the [A/V OUT] terminal.
Set this item according to the monitor to be used.
4:3 : Set this when connecting to a conventional monitor (4:3).
16:9 : Set this when connecting to a wide monitor (16:9).
Memo :
● When [System Definition] in the [Record Format] menu is set to ASD (DV)B, this item appears
as A---B and cannot be selected.
Component
Output
480i (U model)
576i (E model)
720p
1080i
For selecting the resolution of video output from the [COMPONENT OUT] terminal. Set this item
according to the monitor to be used.
480i : Set this when connecting to a monitor that supports 480i. Selectable when [Frame
& Bit Rate] is set to A60iB, A60pB, A30pB, A24pB.
576i : Set this when connecting to a monitor that supports 576i. Selectable when [Frame
& Bit Rate] is set to A50iB, A50pB, A25pB.
720p : Set this when connecting to a monitor that supports 720p.
1080i : Set this when connecting to a monitor that supports 1080i.
Memo :
● During [HDMI] output, this item appears as A---B and cannot be selected.
HDMI Output
480i
480p
576i
576p
Auto
For selecting the resolution of video output from the [HDMI] terminal.
Set this item according to the monitor to be used. Set this item when images are not properly
displayed on a monitor that supports a maximum output of 1080i.
480i : Set this when connecting to a monitor that supports 480i. Selectable when [Frame &
Bit Rate] is set to A60iB, A60pB, A30pB, A24pB.
480p : Set this when connecting to a monitor that supports 480p. Selectable when [Frame &
Bit Rate] is set to A60iB, A60pB, A30pB, A24pB .
576i : Set this when connecting to a monitor that supports 576i. Selectable when [Frame &
Bit Rate] is set to A50iB, A50pB, A25pB.
576p : Set this when connecting to a monitor that supports 576p. Selectable when [Frame &
Bit Rate] is set to A50iB, A50pB, A25pB.
Auto : Resolution is automatically set according to the connected monitor. Use this setting
under normal circumstances.
HDMI Color
Setting
RGB
Auto
For setting the color format of HDMI signals.
RGB : Outputs RGB signals.
Auto : Outputs upon detecting YCbCr/RGB automatically according to the connected
monitor.
HDMI Enhance
Setting
On
Off
For setting the color range of HDMI signals. When connecting to a PC monitor, set this to AOnB.
On : Set this when connecting to a PC monitor.
Off : Set this when connecting to a conventional monitor.
Audio Monitor
Mix
Stereo
For setting the audio sound of the headphone.
Mix : Outputs mixed sound.
Stereo : Outputs stereo sound.
GY-HM150U_02.fm Page 73 Tuesday, September 6, 2011 10:36 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
