JVC GY-HM150U User Manual

65
Audio Set Menu
* Default values are indicated in bold characters.
* Default values are indicated in bold characters.
Item Setting Values Function
Input1 Mic Wind
Cut
On
Off
For selecting whether to cut the low frequencies of the audio input signals (low-cut).
Set this item to reduce wind noise from the microphone.
On : Enables low-cut on the audio.
Off : Disables low-cut on the audio.
Input2 Mic Wind
Cut
Internal Mic Wind
Cut
On
Off
For selecting whether to cut the low frequencies of the audio input signals (low-cut) from the
built-in microphone. Set this item to reduce wind noise from the microphone.
On : Enables low-cut on the audio.
Off : Disables low-cut on the audio.
Audio Ref. Level
-20dB
-12dB
For setting the audio reference level to be recorded to the SDHC/SDXC card. (Applies to
both [CH-1/CH-2].)
-20dB : Outputs signals of the reference level when the meter is at -20 dBFS.
-12dB : Outputs signals of the reference level when the meter is at -12 dBFS.
Internal Mic Level
-2, -1
Normal
1, 2
For setting the input level from the built-in microphone.
Camera Function Menu
Item Setting Values Function
Bars
On
Off
For setting whether to output color bars.
On : Color bars are output.
Off : Color bars are not output.
Memo :
● When in the Full Auto shooting mode, this item is fixed at AOffB and cannot be selected.
● This item is selectable when [System Definition] in the [Record Format] menu is set to
AHD (MPEG2)B. When ASD (DV)B is set, this item is fixed at AOffB. (A Page 63)
● The menu closes when the setting is changed from AOffB to AOnB.
● When the menu screen is opened while [Bars] is set to AOnB, this item switches to AOffB
automatically.
Tele Macro
On
Off
For selecting whether to set tele macro which shortens the closeup distance at the tele (T)
end of the zoom lens. (A Page 37)
On : This is the tele macro setting. Enables closeup shots up to about 80 cm.
Off : This is the normal setting. Enables closeup shots up to about 1 m.
AE Area
^ For setting the area for brightness correction. (A Page 36)
Memo :
● When in the Full Auto shooting mode, this item cannot be selected.
Switch Set...
For specifying the switch settings of the camera recorder. (A Page 66)
GY-HM150U.book Page 65 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
