JVC GY-HM150U User Manual

63
Record Format Menu
After setting of all items in the [Record Format] menu is complete, select [Set] at the bottom of the screen to apply the new
settings on the camera recorder and switch the record format. A APlease WaitB message appears during switching.
* Default values are indicated in bold characters.
Record Set Menu
Item Setting Values Function
System Definition
HD (MPEG2)
SD (DV)
For selecting a system definition.
HD (MPEG2) : Records in HD (High Definition) quality.
SD (DV) : Records in SD (Standard Definition) quality.
Note :
● The selectable options for the [File Format], [Camera Resolution], and [Frame &
Bit Rate] settings vary depending on the setting of this item.
File Format
For selecting the format of the file to be recorded to the SDHC/SDXC card.
When [System Definition] is
AHD (MPEG2)B
QuickTime
MP4
When [System Definition] is ASD
(DV)B
QuickTime
AVI
Camera Resolution
1920x1080
1440x1080
1280x720
720 x 480
720 x 576
For setting the size of the recorded image when [System Definition] is set to
AHD (MPEG2)B. (Horizontal x vertical)
Memo :
● When [System Definition] is set to ASD (DV)B, this item is fixed as follows for
the different models.
• U model :720 x 480
• E model :720 x 576
● The selectable values of [Frame & Bit Rate] vary according to the setting of
this item.
Frame & Bit Rate
For setting the frame rate and encoding bit rate when [System Definition] is set
to AHD (MPEG2)B.
Selection can be made from 19 combinations of frame rate (60p, 50p, 30p, 25p,
24p, 60i, 50i) and bit rate (HQ (35Mbps) VBR), (SP (25 Mbps/19 Mbps) CBR).
Memo :
● When [System Definition] is set to ASD (DV)B, this item is fixed as follows for
the different models.
• U model :60i
• E model :50i
● The selectable items vary according to the [File Format] and [Camera
Resolution] settings.
When [Camera Resolution] is
A1280x720B
60p (HQ) (U model),
60p (SP), 30p (HQ), 30p
(SP),
50p (HQ) (E model),
50p (SP), 25p (HQ), 25p
(SP), 24p (HQ), 24p (SP)
When [Camera Resolution] is
A1440x1080B
60i (HQ) (U model),
60i (SP),
50i (HQ) (E model),
50i (SP)
When [Camera Resolution] is
A1920x1080B
60i (HQ) (U model),
30p (HQ),
50i (HQ) (E model),
25p (HQ), 24p (HQ)
Aspect Ratio
16:9
4:3
For setting the aspect ratio of the recorded image when [System Definition] is
set to ASD (DV)B.
Memo :
● When [System Definition] is set to AHD (MPEG2)B, this item is fixed at
A16:9B.
GY-HM150U.book Page 63 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
