JVC GY-HM150U User Manual

66
Menu Display and Detailed Settings
Switch Set Item
* Default values are indicated in bold characters.
Camera Function Menu
(continued)
Item Setting Values Function
FAW
None
PRESET
A
B
For assigning the FAW (Full Auto White Balance) function to a position on the [WHT.BAL]
selection switch.
The white balance mode is fixed at AFAWB when the [FULL AUTO] button of the camera recorder
is set to AONB.
None : FAW function is not assigned.
PRESET : Assigns FAW to the PRESET position.
A : Assigns FAW to the A position.
B : Assigns FAW to the B position.
GAIN L
GAIN M
GAIN H
AGC, 18dB, 15dB,
12dB, 9dB, 6dB, 3dB,
0dB
For setting the gain value of each position on the [GAIN] selection switch.
This is fixed at AAGCB when the [FULL AUTO] button of the camera recorder is set to AONB.
(Default values GAIN L: 0dB, GAIN M: 9dB, GAIN H: 18dB)
Zoom Speed
-2, -1
Normal
1
For setting the speed of zoom operation with the set lever (on the LCD monitor) and remote
control.
A-2B is the slowest setting and A1B is the fastest setting.
USER1
USER2
LOLUX/3
C.REVIEW/4
ZEBRA/5
REC/6
By assigning one of the following functions to each of the [USER1]/[USER2]/[LOLUX/3]/[C.REVIEW/4]/[ZEBRA/5]/[REC/
6] buttons, these buttons can be used to control the assigned function (on/off, start, switch).
Set according to the shooting conditions. Usable only in the Camera mode.
(Default values USER1: Focus Assist, USER2: TC/UB, LOLUX/3: Lolux, C.REVIEW/4: Clip Review, ZEBRA/5:
Zebra, REC/6: Rec)
Memo :
● The [REC/6] button is set to ARecB by default, and can be used to start/stop recording. The ARecB function can only
be assigned to the [REC/6] button.
Setting Values Description
None No function is assigned.
Load File Assigns the function of [Load Scene File] in the [Setup File Manage] menu. (A Page 75)
OK Mark Assigns the function of appending/deleting OK marks while recording a clip. This function
operates during shooting. (A Page 41)
Clip Cutter Trig Assigns the function of splitting clips freely during recording. (A Page 41)
Memo :
● This item cannot be used when [Slot Mode] is set to ABackupB. (A Page 64)
● This item cannot be used when [Rec Mode] is set to a value other than ANormalB or APre
RecB. (A Page 64)
Backup Trig Assigns the function of [Backup Rec] in the [Slot Mode] menu. (A Page 64)
AE Area Assigns the function of [AE Area] in the [Camera Function] menu. (A Page 65)
Clip Review Assigns the Clip Review function. (A Page 28)
Rec Stop Assigns the function to stop recording. This function operates during recording only.
Memo :
● When the [Rec Mode] menu is set to AClip ContinuousB or AFrame RecB, it is useful to use
this as the stop button. (A Page 64)
Zebra Assigns the function of [LCD/VF] menu B[Shooting Assist]B[Zebra]. (A Page 70)
Lolux For switching the low-light shooting mode ON or OFF.
Tele Macro Assigns the function of [Tele Macro] in the [Camera Function] menu. (A Page 65)
TC/UB Opens the [TC/UB] menu directly. (A Page 69)
Bars Assigns the function of [Bars] in the [Camera Function] menu. (A Page 65)
Focus Assist Assigns the function of [LCD/VF] menu B[Shooting Assist]B[Focus Assist]. (A Page 70)
GY-HM150U.book Page 66 Monday, September 5, 2011 1:48 AM

JVC GY-HM150U Specifications

General

Sensor type	CCD
Number of CCDs	3
Total megapixels	- MP
Optical sensor size	1/4 \
Digital zoom	- x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	3.7 - 37 mm
Interchangeable lens	-
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Minimum aperture number	1.8
Maximum focal length (35mm film equiv)	390 mm
Minimum focal length (35mm film equiv)	39 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	SDHC, SDXC
Internal storage capacity	- GB
Camera shutter speed	0.0001 - 0.27 s
Display diagonal	2.7 \
Display aspect ratio	16:9
Display resolution (numeric)	230000 pixels
Viewfinder type	Electronic
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Camcorder type	Handheld camcorder
Product color	Black
Video resolutions	720 x 480, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 480i, 480p, 720p
Video formats supported	AVI, MOV, MP4, MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	35 Mbit/s
Audio formats supported	LPCM
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Component video (YPbPr/YCbCr) out	1
Battery voltage	7.2 V
Charging source	AC
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	30 - 80 %
Cables included	AV, Component
Power consumption	7.8 W

Weight and Dimensions

Depth	366 mm
Width	138 mm
Height	179 mm
Weight	1400 g
