KEB COMBIVERT F4-C Applications Manual

33
33
3
ANTRIEBSTECHNIK
3
13
KEB COMBIVERT F4-C
Name: Basis
09.02.98
3
Section
Page
Date
© KEB Antriebstechnik, 1997
All Rights reserved
Chapter
HardwareControl Cards
3.1.1 Survey
3.1 Control Units
Depending on the functional extent and the housing size 3 variants of F4C-control
cards are available.
- for housing size D and E
- no speed control possible
- no brake control
- bus connection via operator
- value ranges in part limited
- for housing size G to P
- complete functional extent
- bus connection via operator or
interface card
- for housing size D and E
- complete functional extent
- bus connection via operator
- usable only in connection with
speed detection card
Part No.: 0A.F4.080-xxxx
Software: V1.4
Part No.: 00.F4.080-xxxx
Software: V2.2
Part No.: 0D.F4.080-xxxx
Software: V2.2
3. Hardware
