KEB COMBIVERT F4-C Applications Manual

3 1
KEB COMBIVERT F4-C
8
Name: Basis
09.02.98
Chapter Section
Page Date
© KEB Antriebsteclnik, 1997
All Rights reserved
Hardware Control Cards
1 2 3 12 21 22 231413
+15....18V
15 18
+
PE
+
30V DC / 1 A
30V DC / 1 A
Out 1
Out 2
Out 3
3.1.8 Wiring of Out-
puts
At transistor output X1.12 a
current of 50mA can be taken,
so that 50mA remain for the
supply of the digital inputs!
At inductive load on the relay
outputs or transistor output a
protective wiring must be
provided (freewheeling diode).
