Keithley 2635 Reference Manual

3-22 Return to Section Topics 2600S-901-01 Rev. C / January 2008
Section 3: DUT Test Connections Series 2600 System SourceMeter® Instruments Reference Manual
Figure 3-24
DUT
Low
10V
+ 
Chassis
External Source
Output low connected
to chassis
Source chassis connected to chassis
earth ground through the power cord
High
Keithley Model 2602/2612
Channel A
LO G
LO
HI G G G
HI
SS
Channel B
LOG
LO
HIGGG
HI
SS
HILO
Chassis
Screw
Low-Noise
Chassis Ground
Banana Jack
Model 2636 SMU connections for the floating configuration shown in
Figure 3-23
Model 2601/2602-1 SMU connections for the floating configuration shown in Figure 3-23
