2600S-901-01 Rev. C / January 2008 Return to Section Topics 13-11
Series 2600 System SourceMeter® Instruments Reference Manual Section 13: Factory Scripts
Table 13-8
KIGeneral TSP test script: SweepVListMeasureI
Function:
Description Performs a voltage list sweep with current measured at every step (point):
• Sets the smu to output the first vlist volts value, allows the source to
settle for
stime seconds and then performs a current measurement.
• Sets the smu to output the next vlist volts value, allows the source to
settle for
stime seconds and then performs a current measurement.
• Repeats the above sequence until the current is measured for the last
volts value. The last point in the list to be measured is
points.
Parameters
smu, vlist, stime, points
smu: SourceMeter Channel (A or B). Defaults to SMU A if all
parameters are omitted when function is called.
vlist: Arbitrary list of voltage source values:
vlist = {value1, value2, ....valueN}
stime: Settling time in seconds. Occurs after sourcing a value and before
performing a measurement.
points: Number of sweep measure points (must be ≥2).
Data
Current measurements, voltage source values and timestamps are stored in
smuX.nvbuffer1.
Example:
myvlist = {-0.1, 0.1, -1, 1, -6, 6, -40, 40, 0, 0}
SweepVListMeasureI(smua, myvlist, 500E-6, 10)
This function performs a 10-point voltage list sweep starting at the first point in
myvlist. Current is measured at every step (point) in the sweep. The source will
be allowed to settle on each value for 500µs before a measurement is performed.
TSP project name: KIFactoryGeneral
TSP test script name: KIGeneral
Firmware version: 1.0.2 and later
SweepVListMeasureI(smu, vlist, stime, points)
