Maintenance Fuses
Fuses
A vehicle's electrical system is pro
tected from electrical overload
damage by fuses.
Blade type
Cartridge type
Multi fuse
BFT
* Left side: Normal, Right side:
Blown
This vehicle has 2 (or 3) fuse panels,
one located in the driver's side panel
bolster, the other in the engine
compartment near the battery.
If any of your vehicle's lights, acces
sories, or controls do not work,
check the appropriate circuit fuse. If
a fuse has blown, the element inside
the fuse will melt.
If the electrical system does not
work, first check the driver's side
fuse panel.
If the replacement fuse blows, this
indicates an electrical problem.
Avoid using the system involved and
immediately consult a professional
workshop. Kia recommends to visit
an authorized Kia dealer/service
partner.
Three kinds of fuses are used: blade
type for lower amperage rating,
cartridge type, and multi fuse for
higher amperage ratings.
