1. Loosen the lock nut and turn the turn
buckle to adjust until the proper toe-
in measurement is obtained.
2. Tighten the lock nut again.
(1) Tie Rod (2) Mounting Nut
S76Oa35a
ADJUSTING PROCEDURE
AIR INTAKE LINE
1.Tightenthe hose clamp rmly if it
is loosened.
2. If damage is found, replace the hose
with its clamp.
t91Oa45a
Refer to "EVERY 50 HOURS" in page
10-9.
REPLACING HYDRAULIC OIL FILTER
EVERY 400 HOURS
REPLACING FUEL FILTER ELEMENT
Refer to "EVERY 100 HOURS" in
page 10-13.
CHANGING FRONT AXLE OIL
Refer to "EVERY 50 HOURS" in page
10-11.
CHANGING TRANSMISSION OIL
Refer to "EVERY 50 HOURS" in page
10-10.
