RECORDING ENGINE RPM
Rated speed PTO
(min
-1
)
Corresponding
engine speed
(min
-1
)
540 2,528
750 2,729
1,000 2,416
(1) PTO Shaft Cover (2) PTO Shaft Cap
PTO SHAFT COVER, SHAFT CAP
Always place the PTO cover in position
and close the cap when the PTO shaft
is not used.
S76o545a
SEVEN PIN ELECTRICAL POW-
ER OUTLET
A standard 7-pin trailer lighting socket
is provided and mounted right side of
the tractor, at the rear of the tractor.
t85o518a
540rpm is displayed on the ta-
chometer board.
•
NOTE
