6
6
-
9
3-POINT HITCH / DRAWBAR
When you do install the front loader, certainly mount the bolt for mounting bracket at indicated point.
•
WARNING
FIXATION POINTS FOR FRONT END LOADER
3 1
4 2
[Clutch housing]
[Flywheel housing]
[Front axle frame]
[Flywheel housing]
[Front axle frame]
[Raer axle & Transmission]
S76O605A
LX500_en_om_06.indd 9 2012-11-27 오후 3:08:37
