NOTE : Implement size may vary depending on soil types and eld conditions.
This KIOTI tractor has been thoroughly tested for proper performance with implements approved by KIOTI. Use with implements
which are not approved by KIOTI and which exceed the maximum specications listed below, or which are otherwise unt for use
with this KIOTI tractor may result in malfunctions or failures of the tractor, damage to other property and injury to the operator or
others. [Any malfunctions or failures of the tractor resulting from use with improper implements are not covered by the warranty.]
IMPLEMENT LIMITATIONS
Item
Model
Tread (max. width)
Lifting Capacity max. loading weight
(24 in. aft of hitch)
Front Rear
LX500L
AG
1,235 mm (48.6 in.) 1,340 mm (52.8 in.)
1,013 Kg (2,233 lbs.)Turf 1,435 mm (56.5 in.) 1,305 mm (51.4 in.)
IND 1,312 mm (56.7 in.) 1,260 mm (49.6 in.)
Item
Model
Actual gures
Trailer loading weight W
3
Max. capacity
Implement weight W
1
and / or size
Max. Drawbar Load W
2
LX500L
As in the following list
(Shown in the next page)
650 kg (1433.0 lbs.) 3,000 Kg (6613.9 lbs.)
T46o301A
Lifting Capacity max. loading weight ........... The max. allowable load which can be put on the 24 in. aft of hitch : W
0
Implement weight ........................................ The implement’s weight which can be put on the lower link : W
1
Max. drawbar load ....................................... W
2
Trailer loading weight ..................................The max. loading weight for trailer (without trailer’s weight) : W
3
