OPERATION
OPERATION
TRAVELING POSTURE FOR MACHINE
WARNING
For general travel, always lock the front frame and rear frame with the articulate lock pin.
Before moving any work equipment control lever, check the distance between the blade and tires.
NOTICE
Pay careful attention to the clearance between the blade and the front tire.
If articulation is carried out with the blade at the propulsion angle, the blade may cut the tire or bend the step.
During general travel, keep the front and rear ends of the blade
evenly raised and positioned within the outer border of the machine
as shown in the right figure.
Raise the blade to the height (A), at least 19 cm (7.5 in) above the
ground.
3 - 107
