SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Item Unit GD555-5
Operating weight (including operator 75 kg (165 lb)) kg (lb) 15,160 (33,428)
Engine model - Komatsu SAA6D107E-1 diesel engine
Flywheel horsepower kW{HP} 104-118-131-144{140-158-176-193}
A Overall length mm (ft in) 8,995 (29' 6")
B Overall height (Tail pipe) mm (ft in) 2,995 (9' 10")
C Overall height (with low profile ROPS cab) mm (ft in) 3,200 (10' 6")
D Overall width mm (ft in) 2,485 (8' 2")
Min. ground clearance mm (ft in) 390 (1' 3")
Min. turning radius mm (ft in) 7,300 (23' 11")
Travel speeds
Travel speed at engine
rated horsepower.
Tire loaded radius:
0.61m (2 ft)
Forward
1st km/h (MPH) 3.4 (2.1)
2nd km/h (MPH) 5.0 (3.1)
3rd km/h (MPH) 7.0 (4.3)
4th km/h (MPH) 10.2 (6.3)
5th km/h (MPH) 15.4 (9.6)
6th km/h (MPH) 22.3 (13.9)
7th km/h (MPH) 30.6 (19.0)
8th km/h (MPH) 44.3 (27.5)
Reverse
1st km/h (MPH) 4.5 (2.8)
2nd km/h (MPH) 9.2 (5.7)
3rd km/h (MPH) 20.3 (12.6)
4th km/h (MPH) 40.3 (25.0)
5 - 2
