Optional Accessories
Close-up lens
No. 153, No. 135, No. 122, No. 110
• Attach the close-up lens in front of the
objective lens to measure extremely small
objects.
CCD camera adapter CS-A14
• When using a C-mount industrial camera,
mount it onto the viewnder by placing this
adapter in-between.
White calibration plate (for 45-0) CS-A20
• Used for object color measurement.
AC adapter AC-A305J/L/M (UBX305)
• Used to supply power from an AC outlet to
the instrument.
Input: 100-240 V 50/60 Hz 0.15 A
Output: 5 V 1 A
Illuminance adapter CS-A15
• Attach this adapter in front of the lens to
measure illuminance of incident light.
9
