Mounting
When you mount the instrument onto a tripod or a jig, use the xing screw hole on the
bottom.
Tripod screw hole: Use this hole to mount the instrument onto a tripod. The screw hole
depth is 6.5 mm.
Measuring distance reference
66
8.5
For dimension details, refer to page 102.
Mount the instrument securely on the tripod to prevent it falling over or dropping.
Otherwise, injury or the damage of the instrument or surrounding objects may result.
26
Preparation
SETTING
