Chapter 2 Before the Repair
2-18
7 Interlock relay 1 A relay to cut power supply when
the interlock is engaged.
"5.9.7 Replacing the
Transformer Unit Relay
(Interlock Relay 1) (Page 5-105)"
8 Analog power supply Supply the power supply (±5V, +24
V) to the LMC (photomultiplier).
"5.9.10 Replacing the Analog
Power Supply (Page 5-110)"
9 Interlock relay 2 A relay to cut power supply when
the interlock is engaged.
"5.9.8 Replacing the Standby
Power Supply Unit Relay
(Interlock Relay 2) (Page 5-106)"
10 Standby power supply A power supply that is constantly
ON.
"5.9.9 Replacing the Standby
Power Supply (Page 5-108)"
11 Halogen power supply Supply the power supply to the
halogen lamp.
"5.9.5 Replacing the Halogen
Power Supply (Page 5-103)"
12 Condenser — "5.9.4 Replacing the Condenser
(Page 5-101)"
13 Circuit protector
(Power supply circuit
breaker)
Turn ON/OFF power supply of the
REGIUS MODEL 110.
"5.9.3 Replacing the Noise Filter
and the Circuit Protector Unit
(Page 5-98)"
14 Noise filter — "5.9.3 Replacing the Noise Filter
and the Circuit Protector Unit
(Page 5-98)"
No. Name Function Reference on replacement
method
