Konica Minolta REGIUS 110 Service Manual

Chapter 3 Troubleshooting
3-45
3.4.10 Image Size is Different (Horizontally)
3.4.11 Top and Bottom of the Image is Trimmed
3.4.12 Sides of the Image is Trimmed
• Communicate the contact if it recur after the response.
3.4.13 Unevenness is Not calibrated
• Confirm if the image can be acquired without correction.
• Confirm if the high voltage switch on LMC is ON.
3.4.14 Unevenness Calibration Data is Too High (MAX-MIN is Over 300
Steps)
No. Cause Response
1 Image size setup value was replaced. Confirm and correct the image size setup value.
No. Cause Response
1 Aperture of the X-ray is not appropriate. Confirm the exposure field.
No. Cause Response
1 Aperture of the X-ray is not appropriate. Confirm the exposure field.
2 Horizontal start point is not appropriate. Confirm and change the horizontal start point.
No. Cause Response
1 Image data used for unevenness
calibration was faulty.
Redo the unevenness calibration with a plate without
any scratch or smudge.
2 (Does not improve after performing the
above action)
• Replace the CF card.
See "5.10.3 Replacing the CF Card (Page 5-118)"
for the procedure to replace the CF card.
• Replace the CIU.
See "5.10.1 Replacing the CIU (Page 5-115)" for
the procedure to replace the CIU.
Im
p
ortant
Always perform the image size adjustment, the image position adjustment, the unevenness
calibration, and the sensitivity calibration after replacing the optical unit.
No. Cause Response
1 Exposure condition of the image used in
the unevenness calibration is not
appropriate.
Redo the exposure with appropriate exposure
condition.
2 Plate or the light condensing unit in the
optical unit is dirty.
Clean the plate and the light condensing unit in the
optical unit.
3 Object was exposed on the image that
was used for the unevenness calibration.
Redo the exposure without any object getting
exposed.
4 Polygon correction data is too large
(over 300 steps)
Replace the optical unit if it is still large after redoing
the unevenness calibration.
See "5.2.5 Removing/Installing the Optical Unit (Page
5-11)" for the procedure to replace the optical unit.
