Chapter 3 Troubleshooting
3-16
3.2.6 06250 ~ 06282: Lock Release Motor Errors
• Error codes S column: Errors at the read operation/calibration.
• Error codes E column: Errors during erase operation.
• Error codes I column: Errors during initialization.
References for response method
•
See "2.5.2 Receiver unit (Page 2-12)" for the position of the Lock Motor and the lock HP sensor.
• See "2.5.8 Framework (Page 2-19)" for the position of the MDU.
• See "5.4.8 Replacing the Lock HP Sensor (Page 5-52)" for the procedure to replace the lock HP
sensor.
• See "5.4.9 Replacing the Lock Motor (Page 5-53)" for the procedure to replace the Lock Motor.
• See "5.10.2 Replacing the MDU (Page 5-116)" for the procedure to replace the MDU.
Error code Description of the error Response
(References to replacement methods are
listed at the end of the table.)
S E I
06250 06265 06280 Lock release motor error
(when initializing)
There was a trouble with the
motor control for the
initialization action of the lock
unit.
1. Check the sliding of the release rod
(plunger pin), and replace the release
pin unit assembly when it does not
slide smoothly.
2. Confirm following and replace the
faulty parts.
• Lock HP sensor
• Sensor wire:
JP45 ~ MCN3 (MDU)
• Lock Motor
• Motor wire:
JP16 ~ MCN3 (MDU)
• MDU
06251 06266 06281 Lock release motor error
(when locking)
There was a trouble with the
motor control for the lock action
of the lock unit.
1. Confirm the status of how the cassette
is set.
(is the cassette set in correct
orientation)
2. Check the sliding of the release rod
(plunger pin), and replace the release
pin unit assembly when it does not
slide smoothly.
3. Confirm following and replace the
faulty parts.
• Lock HP sensor
• Sensor wire:
JP45 ~ MCN3 (MDU)
• Lock Motor
• Motor wire:
JP16 ~ MCN3 (MDU)
• MDU
06252 06267 06282 Lock release motor error
(when releasing)
There was a trouble with the
motor control for the lock
release action of the lock unit.
To Next Page
