Konica Minolta REGIUS 110 Service Manual

Chapter 3 Troubleshooting
3-12
06109 06124 06139 Transporter read sensor error
(when moving to press down
position 2)
Transporter read sensor did not
go OFF when the push plate unit
was moving from the read position
to the press down position.
1. Confirm that there are no foreign
objects between the push plate and
the frame, and remove if there are any.
2. Confirm if there is enough grease on
the drive shaft, nut, or transporter
motor unit, and apply grease if it is not
enough.
3. Confirm following and replace the
faulty parts.
• Transporter read sensor
• Sensor wire:
JP47 ~ MCN4 (MDU)
• Transporter motor
• Motor wire:
JP52 ~ MCN6 (MDU)
• MDU
06110 06125 06140
Transporter motor control error
(when moving to press down
position 2)
There was a trouble with the motor
control when the push plate unit
was moving from the read position
to the press down position.
1. Confirm the ground. (It may cause
noise)
2. Confirm that the antistatic brush right
under the insertion slot has not fallen off.
3. Confirm following and replace the
faulty parts.
• Ground wire of transporter unit
(if it is not broken)
• Transporter motor
• Motor wire:
JP52 ~ MCN6 (MDU)
• MDU
06111 06126 06141
Transporter motor control error
(when moving to HP pass
position)
There was a trouble with the
motor control when the push plate
unit was moving from the read
position to the HP pass position.
06112 06127 06142 Transporter HP sensor error
(when moving to HP 2)
Transporter HP sensor did not
go ON when the push plate unit
was moving from the HP pass
position to the home position,
when it was trying to move from
the press down position to the
home position.
1. Confirm that there are no foreign
objects between the push plate and
the frame, and remove if there are any.
2. Confirm if there is enough grease on
the drive shaft, nut, or transporter
motor unit, and apply grease if it is not
enough.
3. Confirm following and replace the
faulty parts.
• Transporter HP sensor
• Sensor wire:
JP46 - MCN4 (MDU)
• Transporter motor
• Motor wire:
JP52 - MCN6 (MDU)
• MDU
Error code Description of the error Response
(References to replacement methods are
listed at the end of the table.)
S E I
