Konica Minolta REGIUS 110 Service Manual

Chapter 3 Troubleshooting
3-14
References for response method
•
See "2.5.4 Subscan Unit (Page 2-14)" for the position of the encoder and the subscan motor.
• See "2.5.5 Optical Unit/Eraser Unit (Page 2-15)" for the position of the LMD and the LMC.
• See "5.5.3 Replacing the Encoder/Wires (Page 5-68)" for the procedure to replace the encoder.
• See "5.6.1 Replacing the LMD (Page 5-78)" for the procedure to replace the LMD.
• See "5.6.2 Replacing the LMC (Page 5-79)" for the procedure to replace the LMC.
06151 06166 06181 Subscan motor control error
(when moving to mechanical
HP)
There was a trouble with the
motor control when the subscan
was moving from the home
position to the mechanical home
position.
1. Confirm that the fixing shaft of the
simple fixing lock is not lowered.
2. Confirm there are no foreign objects
on the magnet shaft of the subscan
unit, and remove it if there are any.
3. Confirm that it is installed horizontally.
4. Confirm following and replace the
faulty parts.
• Subscan motor (cannot replace
on-site)
• Motor wire: CN2 (LMD)
• LMD
• LMC
06152 06167 06182 Transporter motor control
error (when moving to read
end position)
There was a trouble with the
motor control when the subscan
was moving from the
mechanical home position to the
read end position.
06153 06168 06183 Subscan motor control error
(when moving to mechanical
home position 2)
There was a trouble with the
motor control when the subscan
was moving from the read end
position to the mechanical home
position.
Error code Description of the error Response
S E I
