TECHNICAL SPECIFICATIONS 23
149
Oil capacity, external mechanism 390 ml (13.19 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 153)
Oil capacity, cartridge 175 ml (5.92 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 153)
23.8 Shock absorber
Shock absorber article number A490C467X305000
Shock absorber WP PDS
Lowspeed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Highspeed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload 7 mm (0.28 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 69 N/mm (394 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 72 N/mm (411 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 75 N/mm (428 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 38 mm (1.5 in)
Riding sag 110 mm (4.33 in)
Fitted length 402.7 mm (15.854 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 153)
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, emergency OFF switch EJOT PT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, fuel pump EJOT PT
®
2.5 Nm (1.84 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, radiator hoses clip 2.4 Nm (1.77 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, hose clip, throttle valve
body
M4 5 Nm (3.7 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
