MAINTENANCE WORK ON CHASSIS AND ENGINE 125
600616-10
– Stand the motorcycle upright.
– Place a suitable container under the engine.
– Remove screw . Remove the radiator cap.
– Completely drain the coolant.
– Mount the screw with a new seal ring and tighten it.
Guideline
Plug, drain hole of water pump M10x1 15 Nm
(11.1 lbf ft)
– Install the engine guard. ( p. 130)
9.67Filling the cooling system x
Warning
Danger of poisoning Coolants are poisonous and a health hazard.
– Avoid contact between coolants and skin, eyes and clothing. If fuel gets into your eyes, rinse immediately with water and con-
tact a doctor. Wash affected skin areas immediately with soap and water. If coolant is swallowed, contact a doctor immediately.
Change clothes that have come into contact with coolants. Keep coolants out of the reach of children.
600618-10
– Stand the motorcycle on its side stand on a horizontal surface.
– Remove radiator cap .
