CONTROLS 35

5.30Side stand

100233-10

The side stand  is coupled with the safety electric starter system - see the riding instruc-

tions.

Possible states

• Side stand folded out – The vehicle can be supported on the side stand. The safety

electric starter system is active.

• Side stand folded in – This position is mandatory for all journeys. The safety electric

starter system is inactive.
