CONTROLS 34

100212-10

The gear positions can be seen in the photograph.

The neutral or idle position is between the first and second gears.

5.29Foot brake pedal

100232-10

The footbrake pedal  is located in front of the right footrest.

The footbrake pedal operates the rear brake.
