CONTROLS 30
5.21Combination instrument - TRIP F display
700123-01
If the fuel level drops to the reserve mark, the display automatically changes to TRIP F and
starts to count from 0.0, regardless of the previous display mode.
Info
Parallel to the TRIP F display, the fuel warning light switches on.
5.22Combination instrument - coolant temperature indicator
700124-01
The temperature display consists of 12 bars. The more bars showing, the hotter the coolant.
When the top bar lights up, all bars begin to flash and the temperature warning light starts
to show.
Possible states
• Engine cold – Up to four bars light up.
• Engine at operating temperature – Five to eleven bars light up.
• Engine hot – All twelve bars flash.
