MAINTENANCE WORK ON CHASSIS AND ENGINE 96
100271-10
– Check rubber dampers of the rear hub for damage and wear.
» If the rubber dampers of the rear hub are damaged or worn:
– Change all rubber dampers in the rear hub.
100272-10
– Lay the read wheel on a workbench with the rear sprocket facing upwards and insert the
wheel spindle in the hub.
– To check the play , hold the rear wheel tight and try to rotate the rear sprocket.
Info
Measure the play on the outside of the rear sprocket.
Play in rubber dampers, rear wheel ≤ 5 mm (≤ 0.2 in)
» If the play is more than the specified value:
– Change all rubber dampers in the rear hub.
–
Install the rear wheel. x ( p. 94)
9.43Checking the tire condition
Warning
Danger of accidents Uncontrollable handling behavior caused by a flat tire.
– For your own safety, have damaged tires changed immediately.
